Large Equipment Controllers
The Automated Logic line of Large Equipment Controllers are integrals component of the WebCTRL® building automation system. These controllers have the flexibility to handle the most demanding control applications in the industry. Capable of controlling multiple pieces of equipment simultaneously, these robust BACnet building controllers can support complex control strategies with plenty of memory for schedules, alarms, trends and Fault Detection and Diagnostics (FDD). Fault Detection and Diagnostics (FDD)
OptiFlex™ BACnet Building Controllers
The new BACnet building controller is the latest controller to be added to the OptiFlex family, Automated Logic’s next generation of flexible, scalable building controls. With support for so many I/O points, the OptiFlex BACnet building controller can control multiple pieces of HVAC equipment simultaneously while supporting complex building control strategies. The HVAC equipment can then be managed from any web-enabled device using the WebCTRL building automation system, which provides operators with a robust set of online tools so that they can monitor the health of their equipment in real time – at any time.
Ideal for controlling central plants, air handlers, and rooftop units, the OptiFlex BACnet building controller can be DIN-rail or screw mounted and supports Automated Logic’s communicating sensors for sensing environmental conditions such as temperature, humidity and CO2 in a building. It conforms to the BACnet building controller (B-BC) device, as well as the BACnet Router (B-RTR), and BACnet BBMD (B-BBMD) profiles as defined in the BACnet standard 135-2001 Annex L 2012.
Features
- Supports Gig-E, 1000 Mbps, BACnet IP and DHCP IP addressing
- Local Access Ethernet port at 100 Mbps for system start-up and troubleshooting
- Supports up to 9 I/O expanders in panel configuration or remotely mounted
- Supports up to 9I/O expansion modules in a panel configuration or remote mounted up to 1,000ft away for scalable solutions
- Provides direct connect for power and communication for up to 5 I/O expanders
- All programs and historical data stored in non-volatile memory, eliminating batteries
- Capacitor-backed real-time clock keeps time in the event of power failure or network interruption
- Integration capabilities for connecting and managing up to 200 Modbus points
- Ability to capture BACnet network traffic either continuously or on-demand and save to a file
- Custom-programmable using EIKON® software for the WebCTRL® system, enabling you to create graphic logic sequences for your application.
- Flexible communication port configurations are available for communications to field controllers and routing to other BACnet and non-BACnet devices
- Universal Inputs and Outputs with Hand-Off-Auto override
- Supports OptiPoint™ equipment interfaces
- Supports communicating sensors
